• Compatibility

• Balder 6000 / Balder 10000

• Battery Specification

• 12 V, 7Ah/ 9Ah X 20 (sold separately)

• Features

• Rack or tower installation

• Environment

• Humidity: 20-90 % (non-condensing)

  Temperature: 0-40 grades Celsius

• Physical Dimensions

• Dimensions: 600 x 438 x 133 mm [3U]

  Net weight : 12.8 kg

  Weight with batteries: ~62.8 kg

• Power

• 1000 VA/900 W

• Type

• On-line

• Nominal Input Voltage

• 208/220/230/240 VAC

• Accepted Input Voltage Range

• 80-300 VAC

• Nominal Output Voltage

• 208/220/230/240 VAC - user selectable

• Frequency

• 50 Hz/60 Hz

• Efficiency

• High efficiency up to 97%

• Outlets

• Input 1 x IEC-320 C14

  Output 8 x IEC-320 C13

• Transfer Time to Battery / AC

• Zero

• Typical Backup Time

• 25% Load - 23min 6sec

  50% Load - 10min 8sec

  75% Load - 5min 37sec

  100% Load - 3min 38sec

• Communication Ports

• HID USB / RS232 / EPO / SNMP EBM (optional)

• Software

• http://www.powermonitor. software/

• Battery Type

• Sealed and leak proof maintenance

• Battery Specification

• 3 X GP07122L

• Features

• Internal bypass

  EPO function

  Multifunctional color LCD

  Output Power Factor 0.9

  Generator compatible

  ECO Mode for energy saving

  Software management

  Rack/Tower design

  Easy Battery Replacement

  External battery pack (optional)

• LCD Display

• UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions

• Environment

• 0- 40°C (non-condensing)

• Physical Dimensions

• 438 x 430 x 88 mm

  Weight: 13.7 kg

Eaton Ellipse PRO UPS - Jellemzők

• LCD kijelző valós idejű állapot kimutatással
• Tiszta kimenet az AVR-nek köszönhetően
• Az EcoControl funkciónak köszönhetően akár 20%-kal több energiamegtakarítás, az előző generációs UPS-ekhez viszonyítva
• IEC646431-1 szabványú nagy teljesítményű túlfeszültségvédelem
• Akár 8 kimenet, melyhez számítógép és periférikus eszközök köthetők
• Az extra lapos kivitelnek köszönhetően bármely irodai környezetbe könnyen integrálható
• USB port és a könnyen beállítható Eaton UPS Companion szoftver, mely megengedi a biztonságos leállítást és méri az energiafelhasználást
• Védi az adatkapcsolatokat is, mint Ethernet, internet és telefon vonalak

• Power

• 2000VA / 1800W

• Nominal Input Voltage

• 230Vac

• Accepted Input Voltage Range

• 110-300Vac

• Nominal Output Voltage

• 230Vac

• Frequency

• 40Hz ~ 70Hz

• Outlets

• 3 Outlets with Battery Backup & Surge Protection

• Transfer time

• AC-DC: Zero

  Inverter to Bypass: 4ms

• LCD Display

• AC Mode, Battery Mode, Load Level, Battery Level, Input Voltage, Output Voltage, Overload, Fault and Low Battery

• Communication Port

• USB & RS232

  Optional: Smart SNMP card supported

• Battery Specification

• 12V / 9Ah x 4

• Battery Type

• Sealed and leak proof maintenance

• Software

• Software management included

  Monitor & Control over USB, LAN and Internet

• Features

• Pure Sine Wave Output

  Generator compatible

  Eco Mode

• Operation Temperature

• 0 ~ 40 C

• Efficiency

• Up to 90% Efficency Rates

• Power

• 2000 VA / 1600 W

• Type

• On-line

• Nominal Input Voltage

• 220-240 VAC

• Nominal Output Voltage

• 208/220/230/240 VAC – user selectable

• Frequency

• 50Hz / 60 Hz - user selectable

• Outlets

• 4 x Schuko Battery Backup & Surge Protection

• Transfer Time to Battery / AC

• Typical 0 ms

  Eco mode 4 ms

• Typical Backup Time

• 25% Load - 17 min

  50% Load - 7 min

  75% Load - 3 min

  100% Load - 1 min

• Communication Ports

• HID USB, RS232, EPO, SNMP

• Battery Type

• Sealed and leak proof maintenance

• Battery Specification

• 4 x GP07122L

• Software

• Monitor & Control over USB, LAN and Internet (SNMP card optional)

• Features

• Online (double conversion)

  Pure sine wave output

  Selectable output voltage by user

  Selectable output frequency by user

  Wide Input Range (80V-300V)

  Up to 96% Efficiency Rates

  Software management

  HID USB, RS2322, SNMP port communication

  Generator Compatible

  Auto-restart

  Auto-charge

  Low noise level

• LCD Display

• UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions

• Environment

• Humidity: 0-90 % (non-condensing)

  Temperature: 0-40 grades Celsius

  Noise level: less than 40 dB

• Physical Dimensions

• Dimensions: 390 x 151 x 225 mm

  Weight: 16.6 kg
