Termékleírás
|
Connector Type |
|
|
Category |
Cat 6 |
|
Connector |
2x RJ45(8P8C) Female Ports |
|
Shielding |
Unshielded |
|
|
|
|
Material |
|
|
Housing Material |
Polycarbonate |
|
Contact Material |
Phosphor Bronze with Nickel Plating, thickness = 0.3 mm |
|
Contact Surface Material |
Gold Plating, thickness = 3U (3μin or 0.0762 µm) |
|
PCB Material |
FR-4, thickness = 1.6 mm |
|
|
|
|
Electrical Properties |
|
|
Voltage/Current Rating |
125 VAC RMS / 1.5 A |
|
Insulation Resistance |
≥ 1000 MΩ at 500 VDC |
|
Contact Resistance |
≤ 100 mΩ |
|
Dielectric Strength |
750 VAC RMS, 60 Hz, 1 minute |
|
|
|
|
Mechanical Properties |
|
|
RJ45 Jack |
≥ 750 mating cycles |
|
Wire Gauge |
AWG 22-26 |
|
Wiring Scheme |
T568A/T568B |
|
|
|
|
Environment |
|
|
Operating Temperature |
-25°C to 70°C |
|
Operating Humidity |
RH 10% to 90% (non-condensing) |
|
Storage Temperature |
-40°C to 85°C |
|
Storage Humidity |
RH 5% to 96% (non-condensing) |
|
|
|
|
General |
|
|
Dimension |
14.6 x 19.6 x 29.3 mm (WxHxD) |
|
Net Weight |
4.5 g (dust cap included) |
|
|
|
|
Diagram |
unit: mm |
Szavatosság: a jogszabályi előírások szerint.
