Termékleírás
| Kamera | |
| Képérzékelő | 1/3” Progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Slow Shutter | Yes |
| Aperture | 2.8 mm: F2.2 |
| 4 mm: F2.0 | |
| Optika | 2.8 mm/ 4 mm |
| Lens Mount | M12 |
| Min. szükséges megvilágítás | Color: 0.1 Lux; 0 Lux with IR |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Unified/ Scheduled/ Auto |
| Digital Noise Reduction | 3D DNR |
| WDR | DWDR |
| IR Working Distance | 30m |
| Látószög | 2.8mm: 88.2°/48.7°/106.5°(H/V/D) |
| 4mm: 74.6°/41.3°/88.1°(H/V/D) | |
| LENS | |
| Type | Fixed Focal Lens |
| Focal Length | 2.8/4 mm |
| Aperture | 2.8 mm: F2.2 |
| 4 mm: F2.0 | |
| FOV | 2.8mm: |
| Horizontal FOV: 88.2°, Vertical FOV: 48.7°, Diagonal FOV: 106.5° | |
| 4mm: | |
| Horizontal FOV: 74.6°, Vertical FOV: 41.3°, Diagonal FOV: 88.1° | |
| Lens Mount | M12 |
| DORI Distance | 2.8 mm |
| Detect: 45 m (149 ft) | |
| Observe:19 m (62 ft) | |
| Recognize: 9 m (30 ft) | |
| Identify: 5 m (15 ft) | |
| 4 mm | |
| Detect: 60 m (198 ft) | |
| Observe: 25 m (83 ft) | |
| Recognize: 12 m (40 ft) | |
| Identify: 6 m (20 ft) | |
| Angle Adjustment (Manual) | |
| Range | Pan: 0° to 360° |
| Tilt: 0° to 85° | |
| Rotate: 0° to 360° | |
| ILLUMINATOR | |
| IR LED | Quantity: 1 |
| Range: 30m | |
| Wavelength: 850nm | |
| White LED | N/A |
| Illuminator On/Off Control | Auto/Scheduled/Always on/Always off |
| VIDEO | |
| Max. Resolution | 1920 × 1080 |
| Main Stream | Frame Rate: |
| 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps | |
| 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps | |
| Resolution: | |
| 1920x1080, 1280x960, 1280x720 | |
| Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. | |
| Sub-Stream | Frame Rate: |
| 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps | |
| 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps | |
| Resolution: | |
| 704x576, 640x480, 352x288, 320x240 | |
| Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. | |
| Bit Rate Control | CBR, VBR |
| Video Compression | Main Stream: H.265+/H.265/H.264+/H.264 |
| Sub-Stream: H.265/H.264 | |
| H.264 Type | Main Profile/High Profile |
| H.264+ | Main Stream Supported |
| H.265 Type | Main Profile |
| H.265+ | Main Stream Supported |
| Video Bit Rate | Main Stream: 256 Kbps to 4 Mbps |
| Sub-Stream: 64 Kbps to 512 Kbps | |
| Image | |
| Image Settings | Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software, Rotation(90°/270°) |
| Image Enhancement | BLC/3D DNR/HLC/SmartIR |
| Wide Dynamic Range | WDR |
| SNR | ? 52 dB |
| Image Parameters Switch | Yes | <
